​petronyx,LLC

Our team of CAD designers and drafters have been producing top-of-the-line plans, drawings, and 3D models for a combined 50+ years. We pride ourselves on our team driven approach to design and believe in treating each one of our clients as a part of our team too. We specialize in custom designing packages for a broad range of applications in the energy industry. Whether your process is onshore, offshore, midstream, upstream, usual or unique we have the experience to deliver to your standards.


Our team has crosstrained on mulitiple platforms. The current programs we use in house are AutoCAD 2020, AutCAD Plant 3D 2020, Autocad P&ID 2020 & CADWorx Plant Professional 2019

Design & Drafting
